RadioView Web PACS


DICOM Communications

DICOM 3.0 storage and Query/Retrieve Service Class Provider through DICOM Send / Receive, Parallel DICOM Send

Storage

Online, offline and combined storage for all images available lossless DICOM-compliant compression of stored data

Image Distribution

Image distribution directly from any DICOM archive or modality for both onsite and external communications. Near-instant lossless image communication over any bandwidth and distance.

DICOM

  • DICOM C-STORE (SCP/SCU) for most currently approved DICOM SOP
  • DICOM C-STORE (SCP/SCU) support for JPEG Baselin e, JPEGExtended, JPEG Lossless , and RLE (32-bit and 64-bit OS’s).
  • DICOM C-FIND and C-MOVE (SCP) for Patient Root and Study Root query models. All lHE related query fields are supported to the image
  • DICOM WADO with DICOM mime type support

Work list and Viewer

  • Study Search with - Patient name , Study ID, Study Description Date , Accession Number, Performer Physician
  • 56 x 256 to 5K image size compatible
  • 8, 10, 12, 16, 24, 32bit support
  • Cine play mode adjustable up to 30 fps
  • Loop Selection
  • Standard measurement tools
  • Save active series to JPEG and AVI
  • Support of standard Windows ® printer for referral image print
  • DICOM CD/DVD Recorded can be played back on any Personal Computer having CD/DVD­ - ROM

Image Processing

  • Brightness
  • Contrast
  • Dynamic Zoom
  • Panning
  • Image inversion (Negative)
  • Annotation on images

Annotations

  • Text tool
  • Circle Tool
  • Arrow Tool
  • Annotation on images

Image Streaming

Support for on-demand image streaming when used with RadioView Workstation and Web Viewer.

Unique Advantages

  • Fastest data transfer in lower bandwidth networks with loss less JPEG streaming
  • Loss less JPEG Streaming at lower bandwidth
  • Platform independent Web Viewer for Windows, Apple & Android
  • Tyler made Report Templates
  • Film print layout storage
  • Web based DICOM CD/DVD Publishing
  • Time based Web Viewer link to Referral Doctor

Other Facilities

  • DICOM Paper Printing
  • OLEZA DICOM Publisher
  • Customized Reporting
  • MIP, MPR, VR

RadioView Web PACS

System Interfaces to any vendor’s Digital Cath Lab equipment, C.R. & D.R. System, CT, MRI, 20 Echo System or with any DICOM Compliance modality.

Is a robust, scalable and flexible Picture Archiving Communications System. It delivers advanced digital image analysis, management, communications and storage that realize the full promise of film less workflow throughout the imaging chain at an affordable price.

takes advantage of open, standards-based, scalable architecture to integrate easily with any hospital network.

full DICOM functionality turns an ordinary PC into an advanced workstation. It supports archiving, searching, patient-centric access, representing enhanced productivity and significant cost savings.

solution can be accessed directly by any authorized user, anywhere, streamlining information sharing and ensuring secure access to consistent up-to-date information in a familiar working environment. Although a powerful web PACS.

also can be configured to enable any existing PACS and DICOM archive for fast, lossless image distribution without data modification or conversion to ensure full integrity.

Rules Engine

  • Rules based online compression of studies. Studies can be compressed using JPEG Baseline, JPEG Extended, JPEG Lossless, JPEG 2000 or RLE transfer syntaxes at specified times and compression ratios (for lossy compression).
  • Rules based Auto-Routing

Scalability

  • Database and services can be installed separately and thus reside on separate servers. Clustering of services supported to increase the processing power of the server.
  • 32-bit and 64-bit Windows support

Usability

  • Alerts mechanism to notify administrators when system related errors occur.
  • Import folder - DICOM files can be copied into a folder on a filesystem and the files are automatically imported into the lmageServer.
  • Application log viewer.
  • Auto-recovery of failed jobs.
  • Dashboard provides a snapshot of the entire lmageServer with information like the total Studies, number of Work Queue Items, File System status, and current Alerts.g
  • Series Level Manipulation - Series can be moved and deleted.

QA

  • Configurable policies for dealing with duplicate images sent to the server, including Q/A functionality for comparing duplicate images received.
  • Q/A functionality for detecting and repairing images where demographic data in the image does not match the current demographic data of the study.

File Systems

  • Support for multiple filesystems for online storage including NAS devices. Filesystems can be added at any time
  • Support for filesystem tiering , where studies are initially stored on Tier 1 filesystems and then subsequently migrated to lower tier filesystems. This facilitates having faster performing disk for new studies and less expensive disk for priors where performance isn't as much of an issue.
